Opel 1.6L A16XHT Engine: Features and Characteristics
Opel’s A16XHT engine is a powerful and reliable powertrain designed to deliver excellent performance while maintaining fuel economy and environmental friendliness. Manufactured at Plant Szentgotthard, this engine has been fitted to Opel Insignia and Opel Astra J models since 2013, offering drivers an impressive combination of performance and comfort.
Main Features
- Engine make: A16XHT
- Years of manufacture: 2013 – present time
- Cylinder block material: cast iron
- Power system: injector
- Type: in-line
- Number of cylinders: 4
- Valves per cylinder: 4
- Piston stroke: 81,5 mm
- Cylinder diameter: 79 mm
- Compression ratio: 10.5
- Engine displacement: 1598 cm³
Performance
The A16XHT engine impresses with its power and torque. At standard settings, it can develop up to 170 horsepower at 6,000 rpm and deliver 260 Nm of torque between 1,650 and 3,200 rpm. For the Performance Turbo version, power figures increase to 200 hp at 5,500 rpm and torque reaches 280 Nm at 3,500 rpm.
- Engine power: 170 (200*) hp / 6000 (5500*) rpm
- Torque: 260 (280*) Nm / 1650-3200 (3500*) rpm
Environmental and Performance Characteristics
The engine complies with Euro 5 environmental standards, which confirms its low emissions. Fuel consumption on Opel Insignia and Opel Astra J equipped with this engine is 9.2 liters per 100 km in city mode, 5.4 liters – on the highway, and 6.8 liters – in the mixed cycle. These figures make the A16XHT engine quite economical for its class.
- Environmental standards: Euro 5
- Fuel consumption: city 9.2 liters | highway 5.4 liters | mixed 6.8 liters/100 km
Oil consumption of this engine is up to 0.6 liters per 1000 km, which is standard for modern engines. It is recommended to use oil with viscosity 5W-30. The volume of oil required for oil change is about 4.5 liters, and the oil change interval is every 15,000 km.
- Oil consumption: up to 0.6 liters/1000 km
- What oil to use: 5W-30
- Oil volume: 4.5 liters
- Oil change: every 15000 km
Life and Reliability
According to the manufacturer, the life of the A16XHT engine is about 250 thousand kilometers. However, in practice, the exact data on the resource has not yet been established, which makes this engine interesting for further study and testing in conditions of long-term operation.
- Factory data: 250 thousand kilometers
- Practical life: no data
Tuning
A16XHT engine has a high potential for tuning. With the help of modifications it is possible to increase the power up to 230 horsepower. However, data on how this affects the durability and service life of the engine has not yet been determined.
- Tuning Potential: ~230 horsepower
- No loss of life: no data
Application
This engine was installed in models such as Opel Insignia and Opel Astra J. It provided them with good dynamics and economy, meeting Opel’s high standards.
The Opel A16XHT is a powerful and reliable engine suitable for a variety of operating conditions. Its combination of power, economy and environmental friendliness makes it an excellent choice for mid-size and business class cars. Thanks to its high tuning potential, this engine also attracts the attention of car enthusiasts interested in improving the performance of their vehicles.
Astra A16XHT Engine Troubleshooting and Repair
In 2013 Opel introduced a replacement for the outgoing A16LET series, these are new modern turbo engines with direct injection to optimize fuel consumption, with balancer shafts for softer motor operation, a variable valve timing system is applied, a reliable timing chain is used, a small Garrett turbine blows as much as 1. 9 bar and practically from idle, in the basic version Eco Turbo, the motor gives out impressive 260 Nm, but the very shelf of the moment is narrow and already at 3200 the turbine is blown out… In the overboost mode, the turbine briefly blows up to 2.3 bar, the moment increases to 280Nm and is available up to 4250 rpm… There is also a version Performance Turbo with a reinforced piston, with an output of 200 hp. hp and with 280Nm of torque from 1650 to 3500 rpm, in overboost mode the torque is as much as 300Nm! The operating temperature of the engine, like most Opel engines, is 90C.
This is a very tractive grassroots motor for the city, and despite the high specific power, racers are unlikely to like it. Due to the novelty of the engine, the information on the shortcomings and weaknesses is very little, the article will be supplemented as information and feedback, do not switch).
Opel A16XHT 1.6 SIDI engine tuning
Chip tuning Opel Astra 1.6 SIDI turbo
The situation is like tuning any turbo engine, we go to the tuner and re-shim, they promise to increase power to ~210-220 hp. We put a straight-through exhaust on 63 pipe and cooler kit, 220-230 hp, there is no sense to move further. Given the size of the turbine and the pressure it provides, we can assume that chip-tuning will affect its life.
ENGINE RATING: 4+
